Product Details
Frame/Shock
Carbon Main Frame with Alloy Swingarm
–
From its Virtual 4 Link Kinematic design to geo that allows for easy swaps between 29″ and 27.5″ wheels, this frame is smooth and lively on trail.
Light Ready
–
In order to mount a front or rear light, Scott have already routed the cables in the frame, and there is no need for an extra battery – the power comes straight from the drive unit battery.
Easy Wheel Size Changes
–
No need to change the fork, all you need to do is flip a shock mount chip, change your wheels and off you go. The flip chip allows you to maintain a similar BB height when switching from one wheel size to the other which is key to keeping handling similar for both wheel sizes.
TwinLoc Suspension System
–
With TwinLoc, a rider can effectively control the complete frame, fork, and shock as a system. Why does this matter? A bike with 150mm of suspension travel, correctly set up, has more sag than a bike with 130mm. It’s that extra travel that makes it more fun to ride and more capable on the descents, but the greater sag has an oversized effect on the bike’s geometry and climbing performance. That’s where TwinLoc matters. Via a handlebar remote, you can choose from three bikes in one!
eRide Advanced Design
–
With this new E-Bike generation, the design has been pushed further than ever before. More than a battery integrated into the frame, Scott see the bike as a system where every part must be taken into consideration. To improve integration, they have worked on continuity and design balance from the headtube to the dropouts. Enjoy a bike with a unique character!
Impact Damper
–
The bottom bracket area is exposed to flying rocks or other potential impacts, therefore Scott have developed their own specific skid plate, the “Impact Damper”. Reinforced to handle impacts, it is covered with a rubber layer to reduce noise and ventilated to improve drive unit airflow.
Shock Adjustments
–
Air Spring Pressure / Lever-Actuated Open, Medium, Firm Modes / Rebound
Fox Float Rear Shock
–
A lightweight chassis, EVOL air spring, and dual piston damper with 3-position switch create a pedal-friendly shock that soaks up the bumps and delivers pedal power to the ground with utmost efficiency.
Drive Unit / Battery
Bosch Performance CX Gen 4 Drive Unit
–
The new Performance CX generation is now 48% smaller and 25% lighter compare to the previous generation. More compact but no less powerful, the new Bosch Performance CX Generation 4 comes with a maximum power output of 75Nm and 340%. Choose between 5 assist modes or opt for the comfort of the eMTB mode which automatically adapts the assistance like an automatic gearbox does in a car.
Bosch Power Tube
–
Thanks to their range, long service life, intelligent battery management system and easy handling, Bosch Power Tube lithium-ion batteries are among the most modern on the market. All those decades of Bosch experience has paid off!
Scott eRide Range Extender Compatible
–
Scott eRIDE engineering team has developed a specific mount which is fixed on the bottle cage slots. A standard 500Wh Bosch battery can be added on the Range Extender mount. This result in a total of 1125Wh. To recharge, just one charger is needed. The Bosch digital display will take into consideration both batteries. Focus on your journey and not on your battery level
Fork
Fox 34 Float Performance
–
With a new chassis, lower leg channels, and the fantastic GRIP damper, this ebike-ready 34 is a very capable trail fork.
Fork Adjustments
–
Air Spring Pressure / 3 Position Compression Lever / Rebound
Drivetrain
SRAM SX Eagle
–
SX Eagle is your partner for all rides, all the time, all day. Long days, quick rides and everything in-between, SX Eagle is the ecosystem at its best. With the extended range, all new colors and seamless compatibility with the rest of the ecosystem, SX Eagle is there to maximize the potential of your ride experience.
Brakes
Shimano 4 Piston
–
The system adopts a power transfer system in which the disc brake rotor is pressed by the smaller sized piston at the entrance of the disc brake rotor intake and also by the more powerful larger sized piston at the back. This prevents the wobbling motion of the disc brake rotor and reduces noises significantly.
The 4-piston caliper also allows a wider contact area for the disc brake rotor while keeping the size compact, and the efficient location of pads is adjusted as necessary to stabilize the pressure.
203mm Rotors
Wheel Set
Syncros MD30 | 30mm | Tubeless Ready | 32H
Maxxis Rekon Tires
–
The Rekon is an aggressive trail tire inspired by the Ikon for intermediate and technical terrain. Wide knobs down the middle provide control under braking and L-shaped side knobs assure support when carving loose turns. With confidence like this you can race more and scout less with the Rekon.
Additional Features
Price and Spec Subject to Change
Syncros Trail Fender
Syncros Duncan Dropper 2.5 Seatpost
eBikes can only be shipped via ground. Delivery to AK and HI is unavailable at this time.
Specs
- Biking Type:
Mountain - Used For:
Trail - Wheel Size:
29″ - Gearing:
1 x 12 - Frame Material:
Carbon Fiber - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
Fox 34 Float Performance eMTB+ 3-Position - Stanchion Diameter (mm):
34 - Front Travel (mm):
140 - Rear Shock:
Fox Float Performance - Rear Travel (mm):
140 - Drive Unit:
Bosch Performance CX - Battery:
PowerTube 625Wh - Shifters:
SRAM SX Eagle - Rear Derailleur:
SRAM NX Eagle - Crankset:
FSA CK745 165mm | 34T - Cassette:
SRAM PG1210 | 11-50 T - Chain:
SRAM SX Eagle - ISCG Tabs:
Scott Custom Chainguide - Brake Levers:
Shimano MT520 - Brake Calipers:
Shimano MT520 4-Piston - Rotors:
Shimano 203mm - Headset:
Syncros ER2.0 - Stem:
Syncros FL1.5 - Saddle:
Syncros ER1.5 CrMo Rails - Seatpost:
Syncros Duncan Dropper Post 2.5 - Hubs:
Formula - Rims:
Syncros MD30 | 32H - Spokes:
Stainless Black (32) - Tires:
Maxxis Rekon EXO+ 3C MaxxTerra 29 x 2.6″ - Warranty:
5 Years (Frame)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Top Tube (mm) | 585 | 605 | 635 | 665 |
| Seat Tube (mm) | 410 | 440 | 490 | 540 |
| Stack (mm) | 627 | 631 | 641 | 650 |
| Reach (mm) | 422 | 441 | 461 | 488 |
| Standover Height (mm) | 762 | 767 | 798 | 810 |
| Head Tube Angle (°) | 64.8 | 64.8 | 65.0 | 65.0 |
| Seat Tube Angle (°) | 75.4 | 75.4 | 74.8 | 74.8 |
| Chainstay Length (mm) | 465 | 465 | 465 | 465 |
| Bottom Bracket Height (mm) | 347 | 347 | 347 | 347 |
| Bottom Bracket Drop (mm) | 30 | 30 | 30 | 30 |
| Head Tube Length (mm) | 120 | 125 | 135 | 156 |
| Wheelbase (mm) | 1215 | 1236 | 1258 | 1290 |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
