Product Details
Frame/Shock
Spark 3 Alloy SL 6011 Aluminum Frame
–
With custom butted and hydroformed tubes, a tapered headtube, and Boost spacing, this frame shares its geometry with its carbon Spark cousins.
TwinLoc Suspension System
–
With TwinLoc, a rider can effectively control the complete frame, fork, and shock as a system. Why does this matter? A bike with 150mm of suspension travel, correctly set up, has more sag than a bike with 130mm. It’s that extra travel that makes it more fun to ride and more capable on the descents, but the greater sag has an oversized effect on the bike’s geometry and climbing performance. That’s where TwinLoc matters. Via a handlebar remote, you can choose from three bikes in one!
X-Fusion NUDE 5 RLX Rear Shock
–
With new seal designs and materials chosen to optimize performance and increase durability, this shock is a great match for XC bikes. Tuned for excellent small-bump sensitivity and overall efficiency, this shock is perfect in Scott’s TwinLoc system.
Shock Adjustments
–
Air Spring Pressure / Open, Pedal, Lock Compression Modes / Rebound
Fork
RockShox Judy Silver TK
–
Talk about a resurrection, Judy is back and has a whole new look and feel taking its ques from the award-winning Pike. It’s stiff, yet lightweight and packed with the latest features and performance to meet the demands of modern mountain biking. With a Solo Air spring, TunKey damper, and solid Torque Caps for hte connection with the hub, this fork is a winner.
Drive Train
Shimano XT / Deore 12 Speed
–
A solid mix of dependable Shimano components keeps you chugging along. With a wide gear range, you’ll find one of the 12 speeds perfect for your terrain.
Brakes
Shimano Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Shimano RT-10 Rotors | 180mm
Wheelset
Syncros X-30SE | 30mm | Tubeless Ready | 32H
Schwalbe Wicked Will Tires
–
The new Wicked Will has many faces. Whether you set out on an alpine crossing or the fast trail lap, Wicked Will is the right choice and combines like no other light running and grip. It has a fast-rolling midsection with ramped lugs, and a smooth transition area out to its stable and grippy shoulder knobs.
Additional Features
Syncros Duncan Dropper 2.5 Seatpost
Price and Spec Subject to Change
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
1 x 12 - Frame Material:
Aluminum Alloy - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
2 - Fork:
RockShox Judy Silver TK Solo Air - Stanchion Diameter (mm):
30 - Front Travel (mm):
130 - Front Travel (in):
5.1 - Rear Shock:
X-Fusion NUDE 5 RLX - Rear Travel (mm):
120 - Rear Travel (in):
4.7 - Shifters:
Shimano Deore SL-M6100 - Rear Derailleur:
Shimano XT RD-M8100 SGS Shadow Plus - Crankset:
Shimano FC-MT511-1 32T - Cassette:
Shimano Deore CS-M6100 10-51 T - Chain:
KMC X12 - Bottom Bracket:
Shimano BB-MT500 / Shell 41x92mm - ISCG Tabs:
Scott Custom Chainguide - Brake Levers:
Shimano MT501 - Brake Calipers:
Shimano MT501 - Rotors:
Shimano SM-RT54 CL | 180mm - Headset:
Syncros Acros Angle Adjust | +/-0.6° Head Angle Adjustment - Stem:
Syncros DC 3.0 | Cable Integration System - Saddle:
Syncros Tofino 2.5 - Seatpost:
Syncros Duncan Dropper Post 2.5 - Hubs:
Shimano MT410 Boost - Rims:
Syncros X-30SE 30mm 32H - Spokes:
15G (32) - Tires:
Schwalbe Wicked Will | Performance TLR Addix | 29 x 2.4″ - Warranty:
5 Years (Frame and Swing Arm Only)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Top Tube (mm) | 575 | 605 | 635 | 655 |
| Seat Tube (mm) | 410 | 440 | 490 | 540 |
| Stack (mm) | 593.1 | 593.1 | 602.4 | 611.6 |
| Reach (mm) | 402.7 | 432.7 | 460 | 477.3 |
| Standover Height (mm) | 738 | 746 | 760 | 778 |
| Head Tube Angle (°) | 67.2 | 67.2 | 67.2 | 67.2 |
| Seat Tube Angle (°) | 73.8 | 73.8 | 73.8 | 73.8 |
| Chainstay Length (mm) | 438 | 438 | 438 | 438 |
| Bottom Bracket Height (mm) | 327 | 327 | 327 | 327 |
| Bottom Bracket Drop (mm) | 43 | 43 | 43 | 43 |
| Head Tube Length (mm) | 95 | 95 | 105 | 115 |
| Wheelbase (mm) | 1122 | 1152 | 1183 | 1204 |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
