Product Details
Frame/Shock
Ransom Aluminum Alloy SL 6011 Frame
–
Made from ultra lightweight custom butted tubing and featuring Virtual 4 Link Kinematic suspension, this is an all-mountain platform ready for any trail on the planet.
TwinLoc Suspension System
–
With TwinLoc, a rider can effectively control the complete frame, fork, and shock as a system. Why does this matter? A bike with 150mm of suspension travel, correctly set up, has more sag than a bike with 130mm. It’s that extra travel that makes it more fun to ride and more capable on the descents, but the greater sag has an oversized effect on the bike’s geometry and climbing performance. That’s where TwinLoc matters. Via a handlebar remote, you can choose from three bikes in one!
Fox Nude T EVOL Rear Shock
–
Designed in conjunction with Scott, this shock has three modes that are controlled by the handlebar-mounted remote. Adjust your travel and geometry in an instant, depending on how the trail ahead looks.
Shock Adjustments
–
Air Spring Pressure / Open, Medium, Firm Compression Modes / Rebound
Shock Adjustments
–
Air Spring Pressure, Lockout, Traction and Descend Modes (Linear to Progressive Custom Ramp Adjust in Descend Mode), Rebound Adjust
DT Swiss Thru Axle
–
Working together with DT Swiss, Scott completely revisited the shape of the thru-axle lever to make it more ergonomic and to perfectly fit their frames.
ICCR Cable Routing
–
Routing the cables internally omits bulky external hardware and looks cleaner. The cables can endure a longer lifetime as they are protected within the frame. The entry points are machined alloy removable inserts that come along with the frame and can be chosen according to the setup of the bike. Assembling an electronic group or a dropper post will not be a problem and the look will always be clean-cut.
SW Dropouts
–
These dropouts are designed to be integrated on the thru-axle system thanks to a hollow tubular design that allows a simple and lightweight structure. Available for SRAM and Shimano DM derailleurs, this dropout increases the stiffness and avoids damage to the frame in case of impacts on the rear derailleur.
Integrated Frame Protection
–
From the clever downtube protector under the BB and along the downtube to the noise-silencing stay protector, this is a quiet, fast, and armored ride.
Fork
Fox 38 Float Performance
–
Stiff, smooth, and oh so buttery. Performance Series forks retain the same black anodized 7000 series aluminum upper tubes as Performance Elite, except paired with a GRIP damper. Push-button bleeders are not included but can be purchased separately.
Fork Adjustments
–
Air Spring Pressure | 3-Position Compression Settings via TwinLoc remote | Low-Speed Rebound
Drive Train
SRAM NX Eagle
–
Whether you’re discovering the mountain for the first time or you’re an MTB lifer searching for a no-nonsense, no-worries 1x drivetrain, SRAM NX Eagle is ready for action and ready to take you there. NX Eagle brings you a wide range of gear choices engineered for simplicity and durability, so you can focus on what matters most-the ride ahead.
Brakes
Shimano 4-Piston
–
The system adopts a power transfer system in which the disc brake rotor is pressed by the smaller sized piston at the entrance of the disc brake rotor intake and also by the more powerful larger sized piston at the back. This prevents the wobbling motion of the disc brake rotor and reduces noises significantly.
The 4-piston caliper also allows a wider contact area for the disc brake rotor while keeping the size compact, and the efficient location of pads is adjusted as necessary to stabilize the pressure.
Shimano RT66 Rotors | 203mm F / 180mm R
Wheelset
Maxxis Assegai Front Tire
–
The Maxxis Assegai tire is named after the iron-tipped spear used by the Zulu people of South Africa. Greg Minnaar, a native of South Africa, thought it was a fitting name for a tire ready to do battle on the mountain. The tall knobs punch through dust and loam to find traction, but also offer support and confidence on wet roots and rocks. While other tires excel only in certain conditions, the new Maxxis Assegai is built to go fast everywhere.
Maxxis Dissector Rear Tire
–
Designed in conjunction with Aussie DH racer Troy Brosnan, the Dissector seeks to minimize drag while retaining cornering control.
Syncros Revelstoke 2.5 | 30mm
–
Designed for enduro and trail use, these rims are tough enough to handle all-day punishment without failing deep in the backcountry while staying lightweight enough to accelerate with the lunch ride crew.
Additional Features
Syncros Duncan Dropper 2.0 Seatpost
Fox 38 Fender
Price and Spec Subject to Change
Specs
- Biking Type:
Mountain - Used For:
All-Mountain / Enduro - Gearing:
1 x 12 - Frame Material:
Aluminum Alloy - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
Fox 38 Float Performance - Stanchion Diameter (mm):
38 - Front Travel (mm):
170 - Front Travel (in):
6.7 - Rear Shock:
Fox NUDE T - Rear Travel (mm):
170 - Rear Travel (in):
6.7 - Shifters:
SRAM NX Eagle - Rear Derailleur:
SRAM NX Eagle - Crankset:
SRAM NX Eagle DUB Boost 32T - Cassette:
SRAM NX-PG1210 | 11-50T - Chain:
SRAM NX Eagle - Bottom Bracket:
SRAM DUB PF - ISCG Tabs:
Scott Custom Chainguide - Brake Levers:
Shimano M6100 - Brake Calipers:
Shimano M6120 - Rotors:
Shimano RT30 | 203mm F / 180mm R - Headset:
Syncros Pro Press Fit E2 - Stem:
Syncros XM1.5 - Saddle:
Syncros Kaslo 2.0 Crmo Rails - Seatpost:
Syncros Duncan Dropper Post 2.0 - Wheelset:
Syncros Revelstoke 2.5 | 28H | 30mm - Front Tire:
Maxxis Assegai 3C MaxxTerra EXO+ 2.6″ - Rear Tire:
Maxxis Dissector 3C MaxxTerra EXO+ 2.6″ - Warranty:
5 Years (frame and swing arm)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Top Tube (mm) | 571.1 | 604.2 | 634.7 | 671.3 |
| Seat Tube (mm) | 420 | 440 | 470 | 500 |
| Stack (mm) | 613.6 | 613.6 | 627.6 | 641.3 |
| Reach (mm) | 406.3 | 439.5 | 466.5 | 499.5 |
| Standover Height (mm) | 744.6 | 746.3 | 760.9 | 776.5 |
| Head Tube Angle (°) | 64.5 | 64.5 | 64.5 | 64.5 |
| Seat Tube Angle (°) | 75.0 | 75.0 | 75.0 | 75.0 |
| Chainstay Length (mm) | 437.9 | 437.9 | 437.9 | 437.9 |
| Bottom Bracket Height (mm) | 353.5 | 353.5 | 353.5 | 353.5 |
| Bottom Bracket Drop (mm) | 22 | 22 | 22 | 22 |
| Head Tube Length (mm) | 100 | 100 | 115 | 130 |
| Wheelbase (mm) | 1182.9 | 1215.9 | 1249.2 | 1288.5 |
