Product Details
Frame/Shock
TwinLoc 2 Suspension System
–
With TwinLoc, a rider can effectively control the complete frame, fork, and shock as a system. Why does this matter? A bike with 150mm of suspension travel, correctly set up, has more sag than a bike with 130mm. It’s that extra travel that makes it more fun to ride and more capable on the descents, but the greater sag has an oversized effect on the bike’s geometry and climbing performance. That’s where TwinLoc matters. Via a handlebar remote, you can choose from three bikes in one!
RockShox Deluxe Select RL3 Rear Shock
–
Deluxe Select delivers a lightweight package with the same proven damping performance of the entire Deluxe family. Now featuring Maxima Plush fluid for added performance and ride quality.
Shock Adjustments
–
Air Spring Pressure / Lockout – Trail – Descend Compression Modes / External Rebound
Evo-Lap Technology
–
Computer modeling leads to an optimized carbon layup that delivers a super light and compact frame that doesn’t sacrifice stiffness, comfort, or impact resistance.
Adjustable Head Angle
Single Pivot Suspension Layout
–
The Spark’s suspension layout has a very specific and proven kinematic and less unsprung mass. Using a flex pivot in the seat stay is an ideal solution for bikes in this travel range. This allows Scott to keep a very lightweight system while still ensuring optimal suspension performance.
Integrated Rear Axle Tool
–
This clever tool features a T25, T30 and a 6 allen key all in one. With these three options you can adjust all pivot hardware and nearly everything else there is to adjust on the bicycle.
Easy Shock Access
Patented Integrated Suspension System
–
This integrated shock platform allows Scott to refine suspension characteristics without adding weight. This design eliminates lateral movements as the shock goes through its compression, making for a more efficient stroke.
DT Swiss Thru Axle
–
Working together with DT Swiss, Scott completely revisited the shape of the thru-axle lever to make it more ergonomic and to perfectly fit their frames.
Fork
RockShox Pike Select RL3 Air
–
Pike Select combines an updated DebonAir air spring with the Charger RC damper, perfect for any trail junket you have planned. With its buttery smooth feel off the top, this fork still maintains a higher ride height for increased confidence in steep terrain. Its Charger RC damper is a proven performer, too.
Fork Adjustments
–
Air Spring Pressure / Low Speed Compression / Rebound
Drive Train
SRAM NX Eagle
–
GX Eagle is your partner for all rides, all the time, all day. Long days, quick rides and everything in-between, NX Eagle is the ecosystem at its best, there to maximize the potential of your ride experience.
Brakes
Shimano Deore Hydraulic Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Shimano RT-64 Rotors | 180mm
Wheelset
Schwalbe Wicked Will Tires
–
The new Wicked Will has many faces. Whether you set out on an alpine crossing or the fast trail lap, Wicked Will is the right choice and combines like no other light running and grip. It has a fast-rolling midsection with ramped lugs, and a smooth transition area out to its stable and grippy shoulder knobs.
Syncros X-30SE | 30mm | Tubeless Ready | 32H
Additional Features
Syncros Duncan Dropper 2.5 Seatpost
Syncros Savona 2.5 V-Concept Channel Seat
Price and Spec Subject to Change
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
1 x 12 - Frame Material:
Carbon Fiber - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
RockShox Pike Select RL3 Air - Stanchion Diameter (mm):
35 - Front Travel (mm):
130 - Rear Shock:
RockShox Deluxe Select RL3 - Rear Travel (mm):
120 - Shifters:
SRAM SX Eagle Trigger - Rear Derailleur:
SRAM NX Eagle - Crankset:
SRAM X1 Eagle DUB 30T - Cassette:
SRAM SX-PG1210 | 11-50T - Chain:
SRAM NX Eagle - Bottom Bracket:
SRAM DUB BB92 Pressfit - Brake Levers:
Shimano MT501 - Brake Calipers:
Shimano MT501 - Rotors:
Shimano RT64 CL | 180mm - Headset:
Syncros Acros Angle Adjust | +/-0.6° Head Angle Adjustment - Stem:
Syncros DC 2.0 - Saddle:
Syncros Savona 2.5 V-Concept Channel - Seatpost:
Syncros Duncan Dropper 2.5 - Wheelset:
Syncros X-30SE | 30mm - Hubs:
Formula 32H - Spokes:
Stainless Black 15G | 1.8mm - Tires:
Schwalbe Wicked Will | Super Ground TLE 67EPI Addix Speed Grip EVO | 29 x 2.4″ - Warranty:
5 Years (Frame)
| Size | S | M |
|---|---|---|
| Top Tube (mm) | 561 | 589 |
| Seat Tube (mm) | 415 | 440 |
| Stack (mm) | 608 | 608 |
| Reach (mm) | 410 | 440 |
| Standover Height (mm) | 759 | 767 |
| Head Tube Angle (°) | 65.8 | 65.8 |
| Seat Tube Angle (°) | 75.7 | 75.9 |
| Chainstay Length (mm) | 437.5 | 437.5 |
| Bottom Bracket Height (mm) | 331.5 | 331.5 |
| Bottom Bracket Drop (mm) | 43.5 | 43.5 |
| Head Tube Length (mm) | 90 | 90 |
| Wheelbase (mm) | 1145 | 1174 |
| Wheel Size | 29″ | 29″ |
