Product Details
Frame/Shock
Spark 3 Carbon Frame with Aluminum Alloy Swingarm
Evo-Lap Carbon Technology
–
Thanks to this extensive computer modeling, Scott optimized the carbon layers in all the parts of the frame. When the parts were bonded together in the first prototypes, the result was a super light and compact frame without sacrificing the stiffness, comfort or impact resistance. This allows them to make the most efficient layup possible.
Fox Nude 5T EVOL Rear Shock
–
Designed in conjunction with Scott, this shock has three modes that are controlled by the handlebar-mounted remote. Adjust your travel and geometry in an instant, depending on how the trail ahead looks.
Shock Adjustments
–
Air Spring Pressure / Open, Medium, Firm Compression Modes / Rebound
Integrated Frame Protection
–
From the clever downtube protector under the BB and along the downtube to the noise-silencing stay protector, this is a quiet, fast, and armored ride.
DT Swiss Thru Axle
–
Working together with DT Swiss, Scott completely revisited the shape of the thru-axle lever to make it more ergonomic and to perfectly fit their frames.
ICCR Cable Routing
–
Routing the cables internally omits bulky external hardware and looks cleaner. The cables can endure a longer lifetime as they are protected within the frame. The entry points are machined alloy removable inserts that come along with the frame and can be chosen according to the setup of the bike. Assembling an electronic group or a dropper post will not be a problem and the look will always be clean-cut.
SW Dropouts
–
These dropouts are designed to be integrated on the thru-axle system thanks to a hollow tubular design that allows a simple and lightweight structure. Available for SRAM and Shimano DM derailleurs, this dropout increases the stiffness and avoids damage to the frame in case of impacts on the rear derailleur.
Light Tuned Suspension
–
When you see a bike with light tuned suspension you know that it comes with suspension optimized for lightweight riders. Scott worked together with their suspension partners to ensure your fork and shock perform at the highest level, no matter your size.
TwinLoc 2 Suspension System
–
With TwinLoc, a rider can effectively control the complete frame, fork, and shock as a system. Why does this matter? A bike with 150mm of suspension travel, correctly set up, has more sag than a bike with 130mm. It’s that extra travel that makes it more fun to ride and more capable on the descents, but the greater sag has an oversized effect on the bike’s geometry and climbing performance. That’s where TwinLoc matters. Via a handlebar remote, you can choose from three bikes in one!
Adjustable Head Angle
Fork
Fox 34 Float Performance
–
Designed for aggressive trail and all-mountain riding, this fork is lightweight and trail-proven. The Float EVOL air spring and FIT Grip damper are known for their plush feel and adjustability, making this fork a perfect match for advanced riders looking for high performance.
Fork Adjustments
–
Air Spring Pressure | 3-Position Compression Settings via TwinLoc remote
Drive Train
SRAM GX Eagle
–
GX Eagle is your partner for all rides, all the time, all day. Long days, quick rides and everything in-between, GX Eagle is the ecosystem at its best. With the all new 520% range, all new colourways and seamless compatibility with the rest of the ecosystem, GX Eagle is there to maximize the potential of your ride experience.
Brakes
Shimano RT66 Rotors | 180mm
Shimano XT Hydraulic Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Wheelset
Syncros Silverton 2.5 | 30mm | 28H | Tubeless Ready
Schwalbe Wicked Will Tires
–
The new Wicked Will has many faces. Whether you set out on an alpine crossing or the fast trail lap, Wicked Will is the right choice and combines like no other light running and grip. It has a fast-rolling midsection with ramped lugs, and a smooth transition area out to its stable and grippy shoulder knobs.
Additional Features
Syncros Duncan Dropper 2.0 Seatpost
Price and Spec Subject to Change
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
1 x 12 - Frame Material:
Carbon Fiber - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
Fox 34 Float Performance - Stanchion Diameter (mm):
34 - Front Travel (mm):
130 - Rear Shock:
Fox Nude 5T EVOL TwinLoc 2 - Rear Travel (mm):
120 - Shifters:
SRAM GX Eagle - Rear Derailleur:
SRAM GX Eagle - Crankset:
SRAM GX Eagle DUB | 30T - Cassette:
SRAM XG1275 / 10-52 T - Chain:
SRAM CN GX Eagle - Bottom Bracket:
SRAM DUB PF - Brake Levers:
Shimano XT - Brake Calipers:
Shimano XT - Rotors:
Shimano SM-RT66 180 / 180mm - Headset:
Syncros Acros Angle Adjust | +/-0.6° Head Angle Adjustment - Stem:
7050 Alloy | 0° Rise - Saddle:
Syncros Celista 2.0 (V-Concept) Channel - Seatpost:
Syncros Duncan Dropper Post 2.0 31.6mm (S 100mm / M, L 125mm) - Wheelset:
Syncros Silverton 2.5 | 30mm | 28H Tubeless Ready - Hubs:
Syncros 6-Bolt | 15 x 110mm Front / 12 x 148mm Rear | XD Driver - Front Tire:
Schwalbe Wicked Will | EVO / Super Race / TLE / Addix Speed Soft | 29 x 2.4″ - Rear Tire:
Schwalbe Wicked Will | EVO / Super Race / TLE / Addix Speed Grip | 29 x 2.4″ - Warranty:
5 Years (frame and swing arm)
| Size | S | M |
|---|---|---|
| Top Tube (mm) | 575 | 605 |
| Seat Tube (mm) | 410 | 440 |
| Stack (mm) | 593 | 593 |
| Reach (mm) | 403 | 433 |
| Standover Height (mm) | 738 | 746 |
| Head Tube Angle (°) | 67.2 | 67.2 |
| Seat Tube Angle (°) | 73.8 | 73.8 |
| Chainstay Length (mm) | 438 | 438 |
| Bottom Bracket Height (mm) | 327 | 327 |
| Bottom Bracket Drop (mm) | 43 | 43 |
| Head Tube Length (mm) | 95 | 95 |
| Wheelbase (mm) | 1122 | 1152 |
| Wheel Size | 29″ | 29″ |
