Product Details
Frame/Shock
Scale Alloy 6061 Frame
–
Made from custom-butted 6061 aluminum alloy tubing, this frame is strong and light.
DT Swiss Thru Axle
–
Working together with DT Swiss, Scott completely revisited the shape of the thru-axle lever to make it more ergonomic and to perfectly fit their frames.
RideLoc Remote
–
This lever can lock out your fork for climbs and maximum efficiency.
ICCR Cable Routing
–
Routing the cables internally omits bulky external hardware and looks cleaner. The cables can endure a longer lifetime as they are protected within the frame. The entry points are machined alloy removable inserts that come along with the frame and can be chosen according to the setup of the bike. Assembling an electronic group or a dropper post will not be a problem and the look will always be clean-cut.
Fork
RockShox Judy Silver TK
–
Talk about a resurrection, Judy is back and has a whole new look and feel taking its ques from the award-winning Pike. It’s stiff, yet lightweight and packed with the latest features and performance to meet the demands of modern mountain biking. With a Solo Air spring, TunKey damper, and solid Torque Caps for hte connection with the hub, this fork is a winner.
Fork Adjustments
–
Air Spring Pressure | TurnKey Lockout via Remote
Drive Train
Shimano 1 x 12 Speed
–
A mix of durable and dependable parts, this Deore / SLX drivetrain has massive range, great chain security, and solid shifting.
Brakes
Shimano Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Shimano RT-10 Rotors | 180mm F / 160mm R
Wheelset
Maxxis Rekon Race Tires
–
This semi-slick tire borrows its tread design from the trail version of the Rekon, but with smaller and shorter knobs. Use it as a rear tire paired with a more aggressive front tread, or front and rear for short track racing.
Syncros MD25 Disc Rims / 32H Shimano Hubs
Additional Features
Price and Spec Subject to Change
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
1 x 12 - Frame Material:
Aluminum Alloy - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
2 - Fork:
RockShox Judy Silver TK Solo Air - Stanchion Diameter (mm):
30 - Front Travel (mm):
100 - Shifters:
Shimano Deore M6100 R - Rear Derailleur:
Shimano SLX M7100 - Crankset:
Shimano MT511 | 30T - Cassette:
Shimano Deore M6100 10-51T - Chain:
KMC X12 - Bottom Bracket:
Shimano MT500 - Pedals:
Femin PF873ZU - Brake Levers:
Shimano MT201 - Brake Calipers:
Shimano MT201 Hydraulic - Rotors:
Shimano RT10 180mm/160mm - Headset:
Syncros OE Press Fit E2 - Stem:
Syncros Alloy 6061 - Saddle:
Syncros Savona 2.5 V-Concept Channel - Seatpost:
Syncros - Hubs:
Shimano MT410 - Rims:
Syncros 32H - Spokes:
Stainless Black 15G | 1.8mm - Tires:
Maxxis Rekon Race 29 x 2.25″ - Warranty:
5 Years (Frame)
| Size | S | M |
|---|---|---|
| Top Tube (mm) | 575 | 600 |
| Seat Tube (mm) | 390 | 440 |
| Stack (mm) | 605 | 605 |
| Reach (mm) | 397 | 422 |
| Standover Height (mm) | 748 | 776 |
| Head Tube Angle (°) | 69.5 | 69.5 |
| Seat Tube Angle (°) | 73.6 | 73.6 |
| Chainstay Length (mm) | 440 | 440 |
| Bottom Bracket Height (mm) | 312 | 312 |
| Bottom Bracket Drop (mm) | 58 | 58 |
| Head Tube Length (mm) | 100 | 100 |
| Wheelbase (mm) | 1092 | 1118 |
| Wheel Size | 29″ | 29″ |
