Product Details
Frame/Shock
Contessa Active 6061 Alloy Frame
Internal Cable Routing
Replaceable Hanger
Fork
Suntour XCR Air Fork
–
This affordable XC fork features externally adjustable rebound, and air spring for more precise set up. The chassis is robust enough to handle XC singletrack and it utilizes Suntour’s proven sealed cartridge design that requires minimal service work.
Fork Adjustments
–
Preload / External Rebound Adjust
Drive Train
Shimano 2 x 9 Speed
–
A mix of durable and dependable parts, this Shimano drivetrain has massive range, great chain security, and solid shifting.
Brakes
Shimano RT-10 Rotors | 160mm
Shimano Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Wheelset
Kenda Booster Tires
–
Fast, light, and full of traction, the Booster is a great all-around tire.
Syncros X-20 | Shimano Hubs | 32H
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
2 x 9 - Frame Material:
Aluminum Alloy - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
Suntour XCR32 - Stanchion Diameter (mm):
32 - Front Travel (mm):
100 - Shifters:
Shimano SL-M3100 - Front Derailleur:
Shimano M3120 Side Swing 2X - Rear Derailleur:
Shimano Deore 3100 9-Speed - Crankset:
Shimano MT210 | 36/22T - Cassette:
Shimano HG200-9 | 11-36T - Chain:
KMC X9 - Bottom Bracket:
Shimano MT500 Hollowtech II Threaded - Pedals:
VP 536 - Brake Levers:
Shimano MT200 - Brake Calipers:
Shimano MT200 - Rotors:
Shimano RT10 | 160mm - Headset:
Syncros OE Press Fit - Stem:
Syncros 3.0 | 7° - Saddle:
Syncros Savona 2.5 V-Concept - Seatpost:
Syncros 3.0 - Hubs:
Shimano TX505 - Rims:
Syncros X-20 Disc | 32H - Spokes:
14G Stainless Black - Tires:
Kenda Booster 27.5 x 2.4″ - Warranty:
5 Years (Frame)
| Size | XS | S | M |
|---|---|---|---|
| Top Tube (mm) | 560 | 585 | 600 |
| Seat Tube (mm) | 355 | 395 | 440 |
| Stack (mm) | 552 | 575 | 612 |
| Reach (mm) | 402 | 420 | 419 |
| Standover Height (mm) | 678 | 704 | 750 |
| Head Tube Angle (°) | 68.0 | 68.0 | 68.5 |
| Seat Tube Angle (°) | 74.0 | 74.0 | 73.5 |
| Chainstay Length (mm) | 435 | 435 | 450 |
| Bottom Bracket Height (mm) | 308.5 | 308.5 | 316 |
| Bottom Bracket Drop (mm) | 44 | 44 | 60 |
| Head Tube Length (mm) | 95 | 100 | 110 |
| Wheelbase (mm) | 1087 | 1115 | 1102 |
| Wheel Size | 27.5″ (650b) | 27.5″ (650b) | 29″ |
