Product Details
Frame/Shock
Contessa Active 6061 Alloy Frame
Internal Cable Routing
Replaceable Hanger
Fork
Suntour XCR Air Fork
–
This affordable XC fork features externally adjustable reabound and air spring for more precise set up and a hydraulic lockout that can be used on the fly. The chassis is robust enough to handle XC singletrack and it utilizes Suntour’s proven sealed cartridge design that requires minimal service work.
Fork Adjustments
–
Preload / External Rebound Adjust / Hydraulic Lockout
Drive Train
Shimano XT / Deore 2×11 Speed
–
A solid mix of dependable Shimano components keeps you chugging along. With a wide gear range, you’ll find one of the 22 speeds perfect for your terrain.
Brakes
Shimano Disc Brakes
–
Controllable stopping power, all in a lightweight 2-piston trail brake. These feature Shimano’s famous reliability and ease of setup.
Shimano RT-10 Rotors | 180mm F / 160mm R
Wheelset
Kenda Booster Tires
–
Fast, light, and full of traction, the Booster is a great all-around tire.
Syncros X-20 | Shimano Hubs | 32H
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
2 x 9 - Frame Material:
Aluminum Alloy - Brake Type:
Hydraulic Disc - Water Bottle Mounts:
1 - Fork:
Suntour XCR32-RL-R - Stanchion Diameter (mm):
32 - Front Travel (mm):
100 - Shifters:
Shimano Deore M5100 - Front Derailleur:
Shimano Deore M5100 Side Swing - Rear Derailleur:
Shimano XT M8000 SGS - Crankset:
Shimano M5100-B2 | 36/26T - Cassette:
Shimano M5100-11 | 11-42T - Chain:
KMC X11 - Bottom Bracket:
Shimano MT500 - Pedals:
VP 536 - Brake Levers:
Shimano MT200 - Brake Calipers:
Shimano MT200 - Rotors:
Shimano RT10 | 180mm F / 160mm R - Headset:
Syncros OE Press Fit - Stem:
Syncros 3.0 | 7° - Saddle:
Syncros Savona 2.5 V-Concept - Seatpost:
Syncros 3.0 - Hubs:
Formula - Rims:
Syncros X-20 Disc | 32H - Spokes:
14G Stainless Black - Tires:
Kenda Booster 27.5 x 2.4″ - Warranty:
5 Years (Frame)
| Size | XS | S | M |
|---|---|---|---|
| Top Tube (mm) | 560 | 585 | 600 |
| Seat Tube (mm) | 355 | 395 | 440 |
| Stack (mm) | 552 | 575 | 612 |
| Reach (mm) | 402 | 420 | 419 |
| Standover Height (mm) | 678 | 704 | 750 |
| Head Tube Angle (°) | 68.0 | 68.0 | 68.5 |
| Seat Tube Angle (°) | 74.0 | 74.0 | 73.5 |
| Chainstay Length (mm) | 435 | 435 | 450 |
| Bottom Bracket Height (mm) | 309 | 309 | 316 |
| Bottom Bracket Drop (mm) | 44 | 44 | 60 |
| Head Tube Length (mm) | 95 | 100 | 110 |
| Wheelbase (mm) | 1087 | 1115 | 1102 |
| Wheel Size | 27.5″ (650b) | 27.5″ (650b) | 29″ |
