Product Details
Frame/Shock
Junior Alloy 6061 Aluminum Frame
Fork
Rigid 6061 Aluminum Alloy
Drive Train
Shimano 7 Speed Tourney with Revo Grip Shifter
Brakes
Tektro Mechanical Disc with 160mm Rotors
Wheelset
32 Spoke Rims with Formula Disc Hubs
Kenda Booster Tires
–
Fast, light, and full of traction, the Booster is a great all-around tire.
Additional Features
Kickstand
Youth Pedals, Bars, and Grips
Specs
- Biking Type:
Mountain - Used For:
XC - Gearing:
1 x 7 - Frame Material:
Aluminum Alloy - Brake Type:
Cable Disc - Water Bottle Mounts:
1 - Fork:
6061 Aluminum Rigid - Shifters:
Shimano SL-RS 36-7 Revo - Rear Derailleur:
Shimano RD-TY300 7 Speed - Crankset:
Prowheel Alloy Crank 127mm 36T / w/CG PVG Double Cover - Cassette:
SunRace CSM40 7 Speed / 11-34 - Chain:
KMC Z7 - Bottom Bracket:
Feimin / BB68 / Cartridge / Square Taper - Pedals:
MARWI SP-700 with Reflector - Brake Levers:
Tektro JL-510 TS / RS - Brake Calipers:
Tektro SCM-02 Mechanical Disc - Rotors:
160mm - Headset:
Feimin FP-H807 1 1/8″ - Stem:
LEADTEC LCS-7130 50mm - Saddle:
Syncros Youth - Seatpost:
Alloy 26.8x250mm - Hubs:
Formula 32H - Rims:
Shining V-6NS - Spokes:
15G / UCP / Black - Tires:
Kenda K1227 Booster / 20×2.4″ / 30TPI - Warranty:
5 Years
| Size | One Size |
|---|---|
| Top Tube (mm) | 435 |
| Seat Tube (mm) | 260 |
| Stack (mm) | 427 |
| Reach (mm) | 289 |
| Head Tube Angle (°) | 69 |
| Seat Tube Angle (°) | 71 |
| Chainstay Length (mm) | 365 |
| Bottom Bracket Height (mm) | 237 |
| Bottom Bracket Drop (mm) | 30 |
| Head Tube Length (mm) | 110 |
| Wheelbase (mm) | 852 |
